| Material | scheme A | scheme B | scheme C | scheme D | scheme E | scheme F |
| PP T30S | 52% | 45% | 27% | 45% | 40% | |
PP K8003 | -- | -- | 30% | -- | -- | |
| Talc | 20% | -- | 10% | 35% | 35% | |
| glass fiber | -- | 20% | -- | -- | -- | |
| TPP Flame retardant MB | 28% | 35% | 33% | 20% | 25% | |
| anti-dripping | -- | -- | -- | -- | -- | |
| UL94 (1.6mm) | V0 | V0 | V0 | V0 | V0 | |
| 1.6mm 15s | -- | -- | -- | 2s | 0s | |
| UL94(0.8mm) | -- | -- | V0 | V0 | V0 |
| performance | test method | unit | T30S | A |
| density | ASTM-D792 | g/cm3 | 0.9 | 1.34 |
| GWFI | IEC60695-2-12 | C | combustion | 850/30 |
| Flame retardant level | UL941.6mm | -- | combustion | V0 |
| Color | -- | -- | -- | -- |
Flame retardant masterbatch is suitable for PP filling flame retardant V0 system and is recommended for talc powder filling flame retardant. It is difficult to achieve V0 without filling system.
| Material | scheme A | Scheme B | Scheme C |
| ABS417 | 82% | 80% | |
| ASA957 | -- | -- | 79% |
| R04 Flame retardant MB | 18% | 20% | 21% |
| performance | test method | unit | ABS417 | Scheme A | sheme B | scheme C |
| density | ASTM-D792 | g/cm3 | 1.05 | 1.18 | 1.19 | 1.18 |
| tensile strength | ASTM-D638 | -- | 42.5 | 38.5 | 38.8 | 40.8 |
| elongation | -- | -- | -- | -- | -- | 20 |
| Notch impact strength | ASTM-D256 | kJ/m2 | 24 | 13.7 | 12.8 | 4.6 |
| Flame retardant level | UL94 | -- | combustion | 3.2mm V0 | 2mm V0 | 3.2mm V0 |
| bending strength | ASTM-D790 | -- | 66.7 | 63.5 | 63.3 | -- |
| Color | -- | -- | -- | -- | -- | -- |
Injection molding process:
Drying conditions,：using a dehumidifier dryer to dry at 70-75 degrees Celsius for 2-3 hours
